TJC(FA) Load Guard Fork Positioner

Add to Favourites

Quick Overview

The TJC(FA) Load Guard Fork Positioner is designed for handling pallets of varying sizes without increasing the lost load. This unit simply bolts on to existing carriage and helps increase operator productivity by removing the need to manually move forks in position by hand.

FEATURES:
• Used to hydraulically position forks for frequently changing load widths
• Mounts to existing carriage or sideshift
• Load guard provides additional protection and capacity
• Cylinders mounted above carriage to reduce risk of damage
• One additional hydraulic circuit required
• Commonly used in logistics, warehouse and manufacturing industries

Tines and hoses not included. One additional hydraulic function required. Please contact the Forklift manufacturer for the residual capacity of attachment.

Details

Model	Capacity @ LC (kg @ mm)	Mounting Class	Carriage Width (mm)	Opening Range (mm)	Max. Fork Width (mm)	O/All Height (mm)	Unit Weight (mm)
TJC25FA-B001-1260	2500 @ 600	II	1260	370-1160	130	1140	113
TJC25FA-B001-1660	2500 @ 600	II	1660	370-1560	130	1140	129
TJC35FA-C001-1260	3500 @ 600	III	1260	370-1160	130	1240	114
TJC35FA-C001-1660	3500 @ 600	III	1660	370-1560	130	1240	130
TJC50FA-D001-1260	5000 @ 600	IV	1260	390-1180	150	1360	123
TJC50FA-D001-1660	5000 @ 600	IV	1660	390-1580	150	1360	137

NOTES:
• One additional hydraulic circuits required
• Sideshifting range: +/- 100mm
• Hoses not included
• Please contact the forklift manufacturer for the residual capacity of attachment
• Further technical details available upon request, please call 1800 061 998

Model	Description	Lead Time (days)	Price (excl GST)
POA	Price on application		Please Call

* Prices displayed are the net buying price, ex-GST. Contact East West Engineering for availability and lead times
