ZJJ Paper Roll Clamps

The ZJJ Paper Roll Clamps is designed for easy handling of cylindrical goods. All clamps have a 360° rotation function allowing vertical or horizontal placement.

FEATURES:
• Used to for paper roll handling or stacking
• 360°  rotating function enables vertical or horizontal placement
• Available in a range of openings
• Type A Clamps have a fixed short arm suited to handling smaller rolls
• Type B Clamps have an adjustable short arm suited to handling a wide range of roll diameters

• Commonly used in the paper, publishing and printing industries

Hoses not included. Two additional hydraulic functions required. Opening range refers to the distance between arm tips. Also available without sideshifting function
Please contact the Forklift manufacturer for the residual capacity of attachment.

Model Description Price (Excl. GST)
Model: ZJJ25D-B031Description: Paper Roll Clamp - C2Price: POA

Add to Quote

Model: ZJJ25D-B034Description: Paper Roll Clamp - C2Price: POA

Add to Quote

Model: ZJJ25D-C036Description: Paper Roll Clamp - C3Price: POA

Add to Quote

Model: ZJJ30D-C011Description: Paper Roll Clamp - C3Price: POA

Add to Quote

Model: ZJJ30D-C018Description: Paper Roll Clamp - C3Price: POA

Add to Quote

Model: ZJJ35D-C011Description: Paper Roll Clamp - C3Price: POA

Add to Quote

Model: ZJJ35D-D016Description: Paper Roll Clamp - C4Price: POA

Add to Quote

Model: ZJJ50D-D009Description: Paper Roll Clamp - C4Price: POA

Add to Quote

Model: ZJJ50D-D022Description: Paper Roll Clamp - C4Price: POA

Add to Quote

ModelTypeLost Load (mm)HCG (mm)VCG (mm)Unit Weight (kg)To SuitOperation
Model: ZJJ25D-B031Type: ALost Load (mm): 250HCG (mm): 320VCG (mm): 427Unit Weight (kg): 662To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ25D-B034Type: BLost Load (mm): 250HCG (mm): 318VCG (mm): 428Unit Weight (kg): 680To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ25D-C036Type: BLost Load (mm): 250HCG (mm): 371VCG (mm): 459Unit Weight (kg): 740To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ30D-C011Type: ALost Load (mm): 210HCG (mm): 308VCG (mm): 430Unit Weight (kg): 830To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ30D-C018Type: BLost Load (mm): 210HCG (mm): 342VCG (mm): 431Unit Weight (kg): 895To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ35D-C011Type: ALost Load (mm): 221HCG (mm): 314VCG (mm): 460Unit Weight (kg): 1130To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ35D-D016Type: BLost Load (mm): 221HCG (mm): 320VCG (mm): 500Unit Weight (kg): 1215To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ50D-D009Type: ALost Load (mm): 221HCG (mm): 372VCG (mm): 600Unit Weight (kg): 1600To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
Model: ZJJ50D-D022Type: BLost Load (mm): 237HCG (mm): 385VCG (mm): 621Unit Weight (kg): 1500To Suit: Paper RollOperation: Hydraulic Clamp & 360ø Rotation
