CKM Concrete Kibble

The CKM Concrete Kibble is designed for easy transfer of concrete on site by overhead crane.

FEATURES:

Lightweight, yet heavy duty
Adjustable chute allows discharge from the bottom or side of unit
Lever operated from either side, for flexibility of use
Fitted with fork pockets for transport around the work site
Hydraulic Kibble Option (HPP-REMOTE) available to remotely control kibble
Enamel paint finish

Compare

EAST WEST ENGINEERING ARE THE DESIGNER OF THIS PRODUCT AND HAVE PROOF OF CONFORMANCE TO AUSTRALIAN STANDARDS AND CERTIFICATION. BEWARE OF COPY PRODUCTS

Model	Description	Price (Excl. GST)
Model: CKM05	Description: Concrete Kibble - 0.5cu.m	Price: $3,430.00	Compare Product	Add to Quote
Model: CKM05H	Description: Hydraulic Concrete Kibble - 0.5cu.m	Price: $11,060.00	Compare Product	Add to Quote
Model: CKM10	Description: Concrete Kibble - 1.0cu.m	Price: $4,270.00	Compare Product	Add to Quote
Model: CKM10H	Description: Hydraulic Concrete Kibble - 1.0cu.m	Price: $11,890.00	Compare Product	Add to Quote
Model: CKM15	Description: Concrete Kibble - 1.5 cu.m	Price: $6,750.00	Compare Product	Add to Quote
Model: CKM15H	Description: Hydraulic Concrete Kibble - 1.5cu.m	Price: $14,380.00	Compare Product	Add to Quote

Model	Working Load Limit (WLL) kg	Filling Height (mm)	O/A Dimensions (mm)	Unit Weight (kg)	Operation
Model: CKM05	Working Load Limit (WLL) kg: 1500	Filling Height (mm): 1175	O/A Dimensions (mm): 1630 x 1255 x 1500	Unit Weight (kg): 275	Operation: Manual - lever operated
Model: CKM05H	Working Load Limit (WLL) kg: 1500	Filling Height (mm): 1175	O/A Dimensions (mm): 1630 x 1255 x 1500	Unit Weight (kg): 355	Operation: Hydraulic - remotely controlled
Model: CKM10	Working Load Limit (WLL) kg: 3000	Filling Height (mm): 1320	O/A Dimensions (mm): 1760 x 1655 x 1705	Unit Weight (kg): 320	Operation: Manual - lever operated
Model: CKM10H	Working Load Limit (WLL) kg: 3000	Filling Height (mm): 1320	O/A Dimensions (mm): 1760 x 1655 x 1705	Unit Weight (kg): 400	Operation: Hydraulic - remotely controlled
Model: CKM15	Working Load Limit (WLL) kg: 4000	Filling Height (mm): 1510	O/A Dimensions (mm): 1850 x 1655 x 1970	Unit Weight (kg): 415	Operation: Manual - lever operated
Model: CKM15H	Working Load Limit (WLL) kg: 4000	Filling Height (mm): 1510	O/A Dimensions (mm): 1850 x 1655 x 1970	Unit Weight (kg): 495	Operation: Hydraulic - remotely controlled
